How to Overclock Your Monitor's Refresh Rate (Safely)

Published

On this page

You can often squeeze extra refresh rate out of a monitor for free — 60Hz panels to 75Hz, 144Hz to 165–180Hz — by adding a custom rate in your GPU control panel or CRU, then testing for skipped frames. The payoff is smoother motion and a small latency win. This guide walks the safe way to do it, how to verify the overclock actually holds, and honest expectations for what it gets you.

How to Overclock Your Monitor's Refresh Rate (Safely)

A monitor overclock is free extra Hz — as long as you test that the panel actually displays every frame.

Is monitor overclocking safe?

Monitor overclocking is low-risk and fully reversible. Unlike GPU or CPU overclocking, there’s no heat, no wear, and no BIOS involved — you’re only asking the panel to refresh faster than its rated spec. If it can’t, the monitor shows a black screen or falls back to the last working rate, and you revert. The only real failure mode is skipped frames, where the panel accepts the higher rate but silently drops frames, which you’ll test for below.

Method 1: Your GPU control panel (easiest)

Both major GPUs let you add a custom refresh rate without extra software:

  • NVIDIA: open the NVIDIA App (or Control Panel) → Display → Adjust desktop size area → Custom Resolution / Add. Enter your resolution and a higher refresh rate, test it, and apply.
  • AMD: open AMD Software: Adrenalin → Display → Custom Resolutions → Create. Set the higher refresh rate and save.
  • Intel: open the Intel Graphics Command Center → Display → Custom → Add and set a new refresh rate.

Start with a small bump (e.g. 60 → 65Hz) and increase in steps.

Method 2: Custom Resolution Utility (CRU)

CRU gives finer control and works across GPU brands. Add a detailed resolution with your target refresh rate, choose the CVT-RB / CVT-RBv2 timing standard (reduced blanking uses less bandwidth, so it overclocks further), then run CRU’s restart.exe and select the new rate in Windows Display Settings. CRU is also how you set stretched and custom resolutions — see how to get stretched resolution without CRU if you’d rather avoid it for that task.

Step up in small increments

Don’t jump straight to the highest number. Raise the refresh rate a few Hz at a time:

  1. Add the next rate up (e.g. 144 → 150Hz).
  2. Apply it and confirm the desktop still displays.
  3. Run the frame-skipping test (next section).
  4. If it’s clean, try the next step up. If it skips or blacks out, drop back.

Keep the highest rate that passes the frame-skipping test cleanly.

Test for skipped frames (the critical step)

A refresh rate that displays isn’t necessarily a refresh rate that shows every frame. Some panels accept a higher rate but drop frames to keep up — which is worse than not overclocking, because motion looks uneven and the latency benefit disappears.

  • Open the TestUFO frame-skipping test in your browser at the overclocked rate.
  • A clean overclock shows an even, continuous pattern of stripes. Skipping shows duplicated or missing stripes.
  • For a second opinion, photograph the moving pattern with a phone camera — dropped frames show as gaps.

If you see skipping, step the refresh rate back down until the test is perfectly clean.

Bandwidth and cables matter

The higher you push refresh rate, the more bandwidth you need. DisplayPort has the most headroom; HDMI varies by version. If a higher rate won’t hold, try a DisplayPort connection or use CRU’s CVT-RBv2 reduced-blanking timing to fit inside the available bandwidth. See HDMI vs DisplayPort for gaming for how the connections compare.

What overclocking actually gets you

Be honest about the gains:

  • Smoother motion — the main benefit. Extra refreshes mean cleaner tracking and panning.
  • A small latency win. Each finished frame waits less to display: 60→75Hz cuts it from ~16.7 ms to ~13.3 ms; 144→165Hz from ~6.9 ms to ~6.1 ms.
  • Not a lag fix. Overclocking won’t rescue a low frame rate or high system latency. For those, fix FPS and the Windows layer first — see how to minimize input delay.

Enable G-Sync/FreeSync and cap FPS below your new refresh so the overclock stays tear-free. And raise the Windows timer resolution with Tier1Timer so input sampling keeps pace at the higher rate.

Frequently asked questions

Is overclocking a monitor safe?

Yes, monitor overclocking is low-risk and reversible. You are asking the panel to refresh faster than its rated spec; if it can't, the monitor simply shows a black screen or drops back to the last working rate, and you revert. Unlike GPU or CPU overclocking there is no meaningful heat or wear concern at typical refresh-rate bumps, and no BIOS changes are involved. The only real failure mode is skipped frames, which you test for and back off from.

How much can you overclock a monitor?

It varies by panel, but common results are 60Hz to 75–80Hz, 144Hz to 165–180Hz, and 240Hz to 280Hz. The gain depends on the panel, the cable, and the connection — DisplayPort has the most bandwidth headroom. Raise the refresh rate in small steps, test for skipped frames at each step, and keep the highest rate that passes the frame-skipping test cleanly.

Does overclocking a monitor reduce input lag?

A little. A higher refresh rate shortens how long each finished frame waits to be displayed — going 60Hz to 75Hz cuts that wait from about 16.7ms to 13.3ms, and 144Hz to 165Hz from 6.9ms to 6.1ms. The bigger benefit is smoother motion, not latency. Overclocking is mostly worth it for the extra fluidity and the small latency bonus, not as a headline lag fix.

How do I know if my monitor is skipping frames?

Run the TestUFO frame-skipping test (a pursuit-camera pattern) at your overclocked rate. If the panel is dropping frames, the test shows duplicate or missing stripes instead of a clean sequence. You can also photograph the moving pattern with a phone camera. If you see skipping, step the refresh rate back down until the test is clean — a skipping overclock is worse than no overclock.

Can any monitor be overclocked?

Most can be overclocked at least a little, but the amount varies widely and some panels won't budge past their rated spec. Higher-end gaming monitors and those on DisplayPort tend to have the most headroom; budget panels and HDMI connections often have less. There's no harm in trying — if it can't hold the higher rate, it simply reverts, so test in small steps and keep what passes.
